Description
| Specification | ||
|---|---|---|
| CPU | : | ARM — A55 Series — RK 3568 @ 2.0 Ghz |
| OS | Android 11 | |
| MB Size | 120mm*80mm | |
| Power | 12V DC (External/Internal) | |
| Processor | ARM Cortex A 55 Quad-Core 2.0 Ghz | |
| DDR | DDR 2GB Ram | |
| Flash | 16 Gb | |
| Display | HDMI 2160P LVDS (Dual 24bit) Support 1920 x1080P EDP 4K |
|
| Audio | MIC+Speaker+2×8Ω10W AMP | |
| Serial Port | 1 | |
| USB | 4 | |
| Storage | SATA*1 Support to 2T TF / micro SD Support to 64G |
|
| Buttons | 3 Function Keys | |
| WIFI | Built in | |
| Touch Panel | Support USB interface CTP/RTP/PCP … Controller | |
| LAN / RJ 45 | 10/100 M Ethernet | |
| I2c | 6 | |
| GPIO | 6 | |
| Bluetooth | 3.0/4.0 | |
| Touch screen | 15.6”industrial capacitive Touch screen + 10.1” Non Touch Screen | |
| Resolution | 1366 x 768 Pixels | |
| Casing | Strong Rugged metal cabinet |
