Description
| Specification | ||
|---|---|---|
| CPU ARM | : | ARM — A 55 Series — RK 3568 |
| OS | : | Android 11 |
| MB Size | : | 120mm*80mm |
| Power | : | 12V DC (External/Internal) |
| Processor | : | ARM Cortex A 55 Quad-Core 2.0Ghz |
| DDR | : | DDRIII 2G |
| Flash | : | 16 GB |
| Display | : | HDMI 2160P, LVDS (Dual 24bit) Support 1080P, EDP 4K |
| Audio | : | MIC+Speaker+2×8Ω10W AMP |
| Serial Port | : | 1 |
| USB | : | 3 |
| Storage | : | SATA*1 Support to 2T, TF / micro SD Support to 64G |
| Buttons | : | 3 Function Keys |
| QR Code scanner | : | Optional ( Can integrate ) |
| NFC | : | Optional ( Can integrate ) |
| WIFI | : | Built in |
| Touch Panel | : | Support USB interface CTP/RTP/PCP … Controller |
| RJ45 | : | 10/100M Ethernet |
| I2c | : | 6 |
| GPIO | : | 6 |
| Bluetooth | : | 3.0/4.0 |
| Touch screen | : | 11.6” industrial multi touch capacitive screen |
| Printer | : | Thermal receipt Printer with 2″ |
