Description
| Specification | ||
|---|---|---|
| Optical Source | : | Aiming: 617nm LED illumination:6500K LED |
| Imaging Sensor | COMS | |
| Resolution Ratio | 640*480pixels | |
| Image Resolution | ≥ 5mil | |
| Minimum Print Contrast | ≥ 25% | |
| Barcode Types | Standard 1D and 2D | |
| Barcode Sensitivity | Tilt ±65°, Rotate ±30°, Deflection ±55° | |
| Data Interface Port | TTL-23,USB | |
| Mechanical and Electric Performance | ||
| SIZE(Length x Width x Height) | 220mm*70mm*95mm | |
| Net Weight | 220g | |
| Indicator | Beeper and LED light | |
| Working Voltage | 5V | |
| Working Current | 170mA | |
| Accessory | ||
| Data Cable | USB(1.8M) | |
| Operation Manual | One | |
| Environmental Parameter | ||
| Working Temperature | -20°C ~ 60°C | |
| Relative Humidity | 5 ~ 95% | |
| Height range | 5M | |
| IP Rating | IP54 |
