Description
| Specification | ||
|---|---|---|
| printing method | : | Thermal printer |
| Print effective width | 72mm | |
| Print instructions | ESC/TSPL | |
| Resolution | 203dpi | |
| printing speed | 90+/-5mm/s | |
| Print density | 576 dots/line | |
| Character size | 12*24, 24*24 | |
| Connection method | Android ,IOS &Windows | |
| Print interface | Bluetooth +USB | |
| Display screen | Electronic screen LCD | |
| Status Display | Out of paper, open cover, power, charging, lack of power, normal, etc. |
|
| Automatic sleep | support | |
| Interface language | Support Chinese, English, and Portuguese |
|
| Maximum paper width | 80 (adjustable 10-80mm) | |
| Support paper | Thermal receipt paper/adhesive label |
|
| Diameter of paper bin | 50mm | |
| Paper thickness | 0.05-0.15mm | |
| Paper loading method | Easy paper loading structure | |
| Targeting | Photoelectric sensor | |
| Barcode type | Code39,CODE128,QR Code | |
| Font library content | CP852 – Including Central and Eastern European languages (Albanian, Croatian, Czech, English, Finnish, Hungarian, Irish, German, Polish, Romanian, Serbian, Slovak, Slovenian) CP855 – Cyrillic CP857 – Turkish CP858 – “Multilingual CP860 – Portuguese CP862 – Hebrew CP863 – Canadian CP865 – Germanic languages CP866 – Cyrillic/Russian CP1251 – Old Cyrillic CP1253 – Greek CP1254 – Turkish CP1255 – Hebrew |
|
| Standby time | 2 days | |
| Sleep standby | 3 days | |
| Print head life | 100 km | |
| Full power printing | 150m | |
| Charging time | 3 hours | |
| Mechanical behavior | Drop-proof, shock-proof, splash-proof |
|
| Out of paper detection | Opto coupler detection | |
| lithium battery | 2200mA | |
| USB type | Type C | |
| RAM memory | 512Kb | |
| ROM flash | 8M | |
| Processor frequency | 120M | |
| Boot animation | Customizable boot animation | |
| Software adaptation | Self-developed label & receipt app |
|
| adapter | DC 9V, 1A 3.5mm round hole charging port |
|
| Pass the certification | Appearance patent/CCC/CE/FCC/ROHS/BIS(battery-same as MLP360) |
|
| Dimensions | 132*115*61mm | |
| Outer box size | 135*137*112mm | |
| product weight | 0.5kg | |
| working environment | Temperature: 0-45c Humidity: 20-90% |
|
| Storage environment | Temperature: -10-60c Humidity: 10-90% (except paper rolls) |
|
