Description
| Specification | ||
|---|---|---|
|
Optical resolution |
: |
CMOS 640 pixels (H) x 480 pixels (V) |
|
Lighting source |
red LED supplement |
|
|
Resolution |
≥4mil |
|
|
Scanning speed |
2200 times/s |
|
|
Scanning angle |
Roll360°/ Pitch±65°/ Yaw±65° |
|
|
Field of View |
39°(H) X29°(V) |
|
|
Sweeping barcode type |
Paper, thin film medium one-dimensional; mobile phone, flat screen, etc |
|
|
Printing contrast |
20% |
|
|
Error rate |
≤1/2,000,000 |
|
|
Interface type |
USB |
|
|
Promptmode |
Buzzer, LED |
|
|
|
1D: Coda bar、Code 39、Code 32 Pharmaceutical (PARAF)、Interleaved 2 of 5、NEC 2 of 5、Code 93、Straight 2 of 5 Industrial、Straight 2 of 5 IATA，Matrix 2 of 5，Code 11、Code 128、GS1-128、UPC-A、UPC-E、EAN/JAN-8、EAN/JAN-13、MSI、GS1 Data Bar Omni directional、GS1 Data Bar Limited、GS1 Data Bar Expanded、China Post (Hong Kong 2 of 5)、Korea Post. 2D: PDF417, Micro PDF417, GS1 Composite Codes, QR Code, Data Matrix, Maxi |
|
|
Electric voltage |
5V DC |
|
|
Current |
Work Current320mA, Stand-by Current235mA, Starting Current315mA |
|
|
Ambient Light Immunity |
0-100,000 Lux |
|
Mechanical parameters |
||
|
Dimensions |
140.20mm x 84mm x 90.10mm |
|
|
Weight |
249g |
|
Environmental parameter |
||
|
Working temperature |
-20℃～60℃ |
|
|
Storage temperature |
-30℃～70℃ |
|
|
Humidity |
5% to 95% relative humidity ,non-condensing |
|
|
Drop test |
2m |
